Product Details:
Place of Origin: China
Brand Name: CL23B
Model Number: CL23B 102J100V P5mm
Payment & Shipping Terms:
Minimum Order Quantity: 1000 Pieces
Price: RMB 0.18-0.22/PCS
Packaging Details: 1000 per bag in bulk ; 2500 per box braid packaging
Delivery Time: 15-21 work days
Payment Terms: T/T
Supply Ability: 100K Pieces per Month

Durable Polyester Box Capacitor

Type: Metallized Polypropylene Film Capacitor Model Number:: CL23B
Rated Voltage: 100V Lead: Tinned Copper Clad Steel Wire
Voltage Proof: 1.75URDC(5S) Supplier Type:: Original Manufacturer
Color: Grey Size: 7.2*6.5*2.5
Wetting Temperature: -230 ~±5℃ Operating Temperature:: -40℃~+125℃
Capacitor Thickness(MM): ≤3.5 Capacitance Tolerance: ±5%(J): ±5%(J)
High Light:

Durable Polyester Box Capacitor


0.001uf Polyester Box Capacitor


Anti Interference PET Film Capacitor



CL23B 0.001uf/100v 102J Capacitor  Is A Non-Inductive Winding Structure






  1.  Metallized polyester film,stacked construction
  2.   Plastic case(UL94 V-0),epoxy resin sealing
  3.  High dv/dt ability

  Typical Applications:

  1.  By-passing,blocking,coupling,decoupling
  2.  Pulse logic,timing,compact fluorescent lamps
  3.   Inverter for LCD monitors automative DC motor suppression


 Reterence Standard  GB/T 7332(IEC 60384-2)
 Climatic Category  55/125/56
 Rated Temperature  85℃
 Operating Temperature Range  55℃-125℃(+85 C to +125℃:decreasing factor 1.25% per C for Ur  (dc)
 Rated Voltage   50/63V.100V.250V,400V.500V.630V.700V
 Capacitance Range   0.0010uF-2.2uF
 CapacitanceTolerance   +5%(J),±10%(K),±20%(M)
  Voltage Proof  1.4Ua(5s)
  Dissipation Factor Frequency Cn0.1pF Cn>0.1uF
1kHz ≤1.0% ≤1.0%
10kHz ≤1.5% ≤1.5%
100kHz ≤3.0%
  Insulation Resistance UR>100V R≥30000MΩ. CN≤0.33uF RCN≥ 10000s, CN>0.33uF   (20℃,100V,1min)
UR>100V R≥15000MΩ.CN≤0.33uF RCN≥ 5000s,0.33uF< CN≤1.0uF RCN≥ 1000s, CN>1.0uF   (20℃.10V,1min)
